Mobile Passenger Counting System Free IMVS 8 - 36V Wide Voltage Black Color

Place of Origin : Guangdong, China (Mainland)

Brand Name : Visionmaster

Model Number : Passenger Counting System

Price : Negotiable

Certification : CE FCC

MOQ : 1 Set/Sets

Payment Terms : Negotiable

Supply Ability : 2000 sets / month

Delivery Time : 3-5 work days for samples,15-30 work days for large orders

Packaging Details : Neutral packing

Resulution : 720p/960h/d1/hd1/cif

Storage : 128GB SD Card*2

Video Compression : h.264

Color : black

warranty : 12 months

Client software : Free IMVS

Certificate : CE/FCC

wide voltage : 8-36V

Alarm output : YES

Product name : Mobile Passenger Counting System Free IMVS 8 - 36V Wide Voltage Black Color

Contact Now

Mobile Passenger Counting System Free IMVS 8 - 36V Wide Voltage Black Color

Main feature:

  • All aluminum alloy structure design, the appearance of polished silver smelting silver processing, exquisite appearance, full heat dissipation, DC12V;

2) Using SONY 700 TV Lines chip program;

  • Using 4 ¢ 10 infrared light, the angle of distribution is reasonable, a good solution to the flashlight effect;
  • The body circuit itself has good heat dissipation.

The binocular camera is based on the parallax principle design.Set the two cameras at the same time to view the space object P (X, Y, Z), P point will be in the "left eye" and "right eye" imaging Pleft and Pright point, the image of the two cameras in the same plane, then Pleft And Pright Y coordinates of the same, known camera focal length f, through the geometric relationship can be calculated P (X, Y, Z) spatial coordinates.

Mobile Passenger Counting System Free IMVS 8 - 36V Wide Voltage Black Color

Mobile Passenger Counting System Free IMVS 8 - 36V Wide Voltage Black Color

1.1 Electrical Specifications

Power supply +8～+36V 8V～36V, Check the supply voltage of the vehicle battery before use; if it is supplied with more than 36V for a prolonged period, the device may be damaged.
Power output 12V 12V(+/-0.2V), max. current: 3A
ACC detection ≤4V Power off
≥6V Power on
Video input impedance 75Ω Each video input impedance: 75Ω
Video output voltage 2Vp-p 2VP-P CVBS output analog signal which should be adapted by 75Ω of input impedance from the display unit.
I/O interface 1V or below Low level alarm
5V or above High level alarm
Working temperature -25℃ ~ 75℃ In a well-ventilated place
Size

170(W)mmx50(H)mmx142(L)mm

specification:

Image Sensor 1/3” Color SONY CCD
TV System PAL/NTSC
Horizontal Resolution 700TVL
Lens optional f3.6 / 2.8 mm
Effective Pixel Arrey PAL: 976Hx582V; NTSC: 976(H) x 494(V)
Min illumination 0.01 Lux at F1.2
white balance Automatic
Electronic shutter 1/50-1/80000 (s) 1/60-1/80000(s)
Gain automatic gain control
S/N Ratio >48 dB
IR &Infrared LED Range 4 PCS IR LED
IR distance 3m
Horizontal angle of view (90° ) F3.6mm
Work current 210mA
Power Supply 12V DC ±10%
Dimensions 180×64×55 mm(L×W×H)
Net Weight 600 g
Operational Temperature -20 ~ +55° C
Operational humidity 10%~90%
vedio interface Aircraft Round Connector Plug
